SPR-1303 Vortex Optics Spitfire 3X Prism Scope

SKU: SPR-1303 Category:

SPR-1303 Vortex Optics Spitfire 3X Prism Scope

Price:

$427.30

Out of stock

Description
Specifications

Designed specifically for the AR platform, the 3x Spitfireâ„¢ combines an impressive array of high-performance features into a rugged, ultra-compact package. When fast target acquisition in close- to medium-range shooting applications is a priority, the Spitfire excels. Laced with advanced features, the sophisticated prism-based design allows for a more compact optical system without sacrificing optical quality. The DRT (Dual Ring Tactical) reticle is etched directly on the prism to assure consistent point-of-aim at all times with selectable red/green illumination of five intensity levels to match specific conditions.Prism Scopes are not compatible with the VMX-3T Magnifier.

Features:

Optical Features:

Fully Multi-Coated Multiple anti-reflective coatings on all air-to-glass surfaces increase light transmission.
Prism-Based Design Delivers sharp optics and allows for unique reticle designs that are visible with or without illumination.



Construction Features:

Single-Piece Chassis Compact and lightweight.
Waterproof O-ring seals prevent moisture, dust and debris from penetrating for reliable performance in all environments.
Fogproof Nitrogen gas purging delivers fogproof, waterproof performance.
Shockproof Rugged construction withstands recoil and impact.
Hard Anodized Finish Highly durable low-glare matte finish.
Operating Temperature Rated from -22 degrees to +122 degrees Fahrenheit.



Convenience Features:

Variable Mount Heights Comes mounted at a lower 1/3 co-witness height of 40.4 mm from the optic center to base surface. Remove the mount riser if a lower 30 mm mounted height is desired.
Adjustable Brightness Provides five levels of brightness intensity with red and green illumination settings.
Red/Green Reticle Option Allows shooters a choice of dot color.
Battery Life Typical battery life is 250 hours at maximum brightness and 3,000 hours at minimum brightness setting.



Specifications:

Magnification 3 x
Eye Relief 2.8 inches
Field of View 31.5 feet/100 yards
Adjustment Graduation 1/2 MOA
Max Elevation Adjustment 120 MOA
Max Windage Adjustment 120 MOA
Parallax Setting 100 yards
Length 5.5 inches
Weight 15.4*
Product Manual (PDF) Download



Included In the Box:

  • (2) Picatinny Rails
  • T-15 Torx Wrench
  • 2mm Hex Wrench
  • CR2032 battery
  • Flip Caps

Dimensions:

SPR-1303 Vortex Optics Spitfire 3X Prism Scope 6

Reticle:

SPR-1303 Vortex Optics Spitfire 3X Prism Scope 7

EBR-556B (MOA) RETICLE:
The EBR-556B reticle (Enhanced Battle Reticle) is designed around the 5.56 x 45 cartridge to aid in rapid shooting at both near and far ranges—providing holdover and ranging references from 0-500 yards. Etched directly on the prism to assure consistent point-of-aim at all times with selectable red/green illumination of five intensity levels to match specific conditions.

Subtension detail for the Spitfire 3x prism scope with EBR-556B reticle. >

Note

Read the Spitfire 3x Reticle manual for tips on shooting.
