RZR-31805 Vortex Optics Razor HD Gen II 3-18x50 FFP Riflescope with EBR-7C Reticle (MRAD)

SKU: RZR-31805 Category:

RZR-31805 Vortex Optics Razor HD Gen II 3-18x50 FFP Riflescope with EBR-7C Reticle (MRAD)

Price:

$1,835.85

Out of stock

Description
Specifications

The clear choice for hardcore precision, tactical and competition shooters looking for the optimal combination of features and optical quality. The Razor HD Gen II provides long-range shooters the advanced features needed to perform at the highest level, including locking turrets, the integrated L-Tec zero stop and a first focal plane reticle for when shots need to be taken quickly from any magnification.

Features:

Optical Features:

APO System Index-matched lenses correct color across the entire visual spectrum.
Optically Indexed Lenses Optimize image sharpness and brightness from edge to edge.
HD Lens Elements Premium extra-low dispersion glass delivers the ultimate in resolution and color fidelity, resulting in high-definition images.
XRPlus Fully Multi-Coated Ultimate anti-reflective coatings on all air-to-glass surfaces provide maximum light transmission for peak clarity and the pinnacle of low-light performance.
Plasma Tech Cutting edge coating application process provides unparalleled coating durability and performance
First Focal Plane Reticle Scale of reticle remains in proportion to the zoomed image. Constant subtensions allow accurate holdover and ranging at all magnifications.
Glass-etched Reticle Allows for intricate reticle design. Protected between two layers of glass for optimum durability and reliability.
Illuminated Reticle Provides precise aiming under low-light conditions.

Construction Features:

Tube Size 34 mm diameter provides maximized internal adjustment and strength.
Single-Piece Tube Maximizes alignment for improved accuracy and optimum visual performance, as well as ensures strength and waterproofness.
Aircraft-Grade Aluminum Constructed from a solid block of aircraft-grade aluminum for strength and rigidity.
Waterproof O-ring seals prevent moisture, dust and debris from penetrating the riflescope for reliable performance in all environments.
Fogproof Argon gas purging prevents internal fogging over a wide range of temperatures.
Shockproof Rugged construction withstands recoil and impact.
Hard Anodized Stealth Shadow Finish Highly durable hard-coat anodization provides a low-glare matte surface and helps camouflage the shooter’s position.
ArmorTek Ultra-hard, scratch-resistant coating protects exterior lenses from scratches, oil and dirt.
L-Tec Turrets Integrated locking mechanism prevents accidental adjustments. Turrets provide fast, accurate, easily read elevation and windage adjustments. Patent pending.
External Rotation Indicator Provides quick visual and tactile reference of elevation turret’s rotational position.
Locking Illumination Locks illumination at preferred setting.
Side Focus Adjustment located on left side of turret housing is easily accessible from shooting position. Provides optimal image focus and parallax removal.

Internal Mechanism Design Features:

L-Tec Zero Stop Prevents elevation turret from dialing below sight in range using rugged steel components. Internal mechanisms stay free of sand, dirt, dust, moisture and other foreign materials—even when setting the zero-stop position.
Maximized Turret Zero Adjustment Turret design allows expanded adjustment range when L-Tec zero stop feature is disengaged for zeroing purposes.
Micro Adjust Zero Setting Infinite zero setting positions allow zero to be set between clicks for optimal accuracy.
Friction Reduction System Heat-treated, hardened-steel pad floats on the end of the turret screw and interfaces with a hardened steel ring on the erector tube for steel-on-steel contact. Prevents galling or deformation of the erector screw contact point for superior durability and repeatability.
Turret Screws Provides low-friction, wear-resistant performance: precision-machined from a silicon-brass alloy and treated with an advanced dry-film lubricant. Turret screw threads are precision machined to sub-2 micron tolerances (less than 78-millionths of an inch).
Erector Tube System Precision-machined from aircraft-grade aluminum with anti-galling properties for a lighter weight, strong, durable tube. Stainless Steel offset coil spring erector biasing system withstands much higher stresses than traditional flat erector springs and al.

Convenience Features:

Fast Focus Eyepiece Allows quick and easy reticle focusing.
Locking Side Illumination Easily accessible and lockable illumination dial is located on the left side of turret housing. Features eleven intensity levels of illumination with off positions between each setting.

Specifications:

Magnification 3-18 x
Objective Lens Diameter 50 mm
Eye Relief 3.7 inches
Field of View 37.8-6.25 feet/100 yards
Tube Size 34 mm
Turret Style L-Tec
Adjustment Graduation .1 MRAD
Travel per Rotation 10 MRAD
Max Elevation Adjustment 28.5 MRAD
Max Windage Adjustment 10 MRAD
Parallax Setting 25 yards to infinity
Length 14.4 inches
Weight 46.5 ounces
Product Manual (PDF) Download
Product Manual 2 (PDF) Download

Included In the Box:

  • 4-inch sunshade
  • 2mm hex wrench
  • CR2032 battery
  • Lens cloth

Dimensions:

RZR-31805 Vortex Optics Razor HD Gen II 3-18x50 FFP Riflescope with EBR-7C Reticle (MRAD) 6

LENGTHS
L1 L2 L3 L4 L5 L6
14.4 2.0 2.2 6.1 4.1 4.1



HEIGHTS
H1 H2
2.32 1.81

* Dimensions measured in inches.

Reticle:

RZR-31805 Vortex Optics Razor HD Gen II 3-18x50 FFP Riflescope with EBR-7C Reticle (MRAD) 7

EBR-7C (MRAD)

Packed with useful subtension data for long-range competition shooting or hunting, the EBR-7C is a hashmarked ranging reticle available in first focal plane. A windage tree in the lower two quadrants is perfect for fast follow-up corrections for both wind and elevation. Unique to the 7C, the numbers on the lower stadia have moved to the outside of the windage dots for less obstruction around the vertical stadia itself.

Subtension detail for the Razor HD Gen II 3-18x50 riflescope with EBR-7C MRAD reticle. >
