RAZOR® AMG™ UH-1™ Gen 1 and Gen 2 Holographic Sight (1 MOA DOT)

SKU: N/A Categories: ,

RAZOR® AMG™ UH-1™ Holographic Sight (1 MOA DOT)




Introducing a new paradigm in Holographic Weapon Sights. The UH-1™ uses our revolutionary Fusion Hologram with Quantum Well Light Control (FHQ™) technology to deliver the first holographic sight to meld the durability and energy efficiency of a red dot with the impressive sight picture, zero-distortion, and reticle pattern of a holographic sight.

Integrated Mount - Quickly attaches to any Weaver or Picatinny rail with the integrated mount.

RAZOR® AMG™ UH-1™ Gen 1 and Gen 2 Holographic Sight (1 MOA DOT) 5


 Optical Features:

Fully Multi-Coated  Anti-reflective lens coatings on every lens surface allow for brighter views.
Brightness Settings  15 Levels
Unlimited Eye Relief  Non-critical eye relief for rapid target acquisition.
Parallax Free  All red dot and holographic sights will exhibit some small amount of parallax. Matching current industry practice, this small amount would be considered  “parallax free” and will make a negligible difference in the UH-1’s performance.


Construction Features:

Shockproof  Rugged construction withstands recoil and impact.
ArmorTek  Ultra-hard, scratch-resistant coating protects exterior lenses from scratches, oil, and dirt.
Rear Facing Controls  Easily power up and click through 15 levels of intensity.
FHQ™ Technology  Virtually eliminates stray light emissions for stealth-shooter-signature in low light and prevents eyepiece glare common to other holographic sights.
Integrated Mount  Quickly attaches to any Weaver or Picatinny rail with the integrated mount
Micro USB Port  For use with LFP123A rechargeable battery.


Battery Options:

CR123A CR123A battery is included with the UH-1. This option will provide the best battery life for continuous use.
LFP123A The UH-1 also runs on the LFP123A, the high-end rechargeable version of the CR123A. Charge the battery using the Micro USB port and it will recharge while in the sight. This battery does not have as long of life for continuous use as a standard CR123A but does provide the advantage of recharging.

You can also recharge LFP123A batteries in a separate recharger plugged directly into an AC wall outlet. If you have multiple batteries and an external charger you can always charge one battery while using the other.

RCR123A You can use this battery in a pinch. It is rechargeable, but it won’t take a full charge through the USB port and may fail after a couple of hundred rounds due to recoil and will not recharge. It will not damage the unit, but you will not get optimal performance from this battery.


Magnification 1 x
Eye Relief Unlimited
Dot Size 1 MOA
Adjustment Graduation 1/2 MOA
Travel per Rotation 16.5 MOA
Max Elevation Adjustment 200 MOA (Gen 1)

100 MOA (Gen 2)

Max Windage Adjustment 150 MOA (Gen 1)

100 MOA (Gen 2)

Parallax Setting Parallax Free
Length 3.5 inches

(Gen 1)

3.9 inches (Gen 2)

Weight 11.8 oz
Product Manual (PDF) Download


Included In the Box:

  • CR123A Battery



The daylight bright red dot is easy to see and paints targets regardless of lighting conditions or background.

Subtension detail for Razor 3 MOA red dot. >

RAZOR® AMG™ UH-1™ Gen 1 and Gen 2 Holographic Sight (1 MOA DOT) 6

Additional information




Generation I, Generation II
